More power, more performance.

The DF40A is the only engine in the 40 HP class to offer DOHC performance, and also the only to incorporate a maintenance-free, oil-bathed timing chain, which provides the outboard with improved durability and maintenance-free operation. With larger displacements for increased power and performance, Suzuki’s Lean Control System improves fuel economy with designs that are more compact and lighter in weight than their predecessors. The new DF40A engines also include the Suzuki Troll Mode System. The Boating Writers of America presented Suzuki Marine with the NMMA Innovation Award for the DF40A/DF50A, during the 2011 Miami Boat Show.



See Product Brochure here.

MORE POWER, MORE PERFORMANCE.

Features

  • 1
  • 2
DF-40-A

Go your own speed.

Glide into your favorite honeyhole with Suzuki’s Troll Mode System. The engine’s revs can be adjusted in 50 rpm intervals, giving you precise control pressing the Troll Mode control switch from idle up to 1200 rpm, allowing you control over your wake and speeds.

DF40ATL_RC_White_Back_from2021MY

Running like clockwork

The DF40A comes equipped with digital sequential electronic fuel injection, meaning it reads the electronic control unit monitors throttle setting, engine RPM, cylinder wall and air-intake temperature and atmospheric pressure all at once. All of these considerations cause the fuel injection to enter the combustion chamber at the most optimal opportunity, offering smoother and faster acceleration, crisp throttle response and reliable starting no matter what the conditions or temperature are.

Specifications

MODEL
DF40A
Body Color
Pearl Nebular Black or White
Recommended Transom Height (inches)
L: 20
Starting System
Electric
Weight LBS
L: 229
Engine Type
DOHC 12-Valve
Fuel Delivery System
Multi Point Sequential Electronic Fuel Injection
No. Of Cylinders
3
Piston Displacement inches (cc)
57.4 (941)
Bore X Stroke Inches (mm)
2.85 x 2.99 (72.5 x 76)
Maximum Output HP
40
Operating Range (RPM)
5000 - 6000
Steering
Remote (Tiller Kit Optional)
Choke
N/A
Oil Pan Capacity quarts (liter)
2.9 (2.7)
Ignition System
Solid State Direct Ignition
Alternator
12V 19A
Trim Position
Power Trim and Tilt
Gear Ratio
2.27:1
Standard Propeller
Optional See Dealer
Propeller Selection
9 - 17
